ASRock X870E Taichi matična ploča

Name: ASRock X870E Taichi matična ploča
Brand: ASRock
SKU: 4710483947421

Cena: 54.530 u 1 prodavnici

Bar-kod: 4710483947421

Tip: AMD
Format matične ploče: E-ATX
Tip RAM memorije: DDR5
Gaming

Sve ponude

+6~~84.130~~54.530 Posetite prodavnicuPosetite

Kupci imaju mogućnost da samostalno predlože cenu proizvoda, a prodajna služba se obavezuje da odgovori sa trenutno najboljom ponudom.

Besplatna dostava za proizvode koji su označeni stikerom besplatna isportuka na sajtu prodavca

Plaćanje gotovinom prilikom preuzimanja paketa

Online plaćanje platnim karticama

Dostava u roku od 48h od trenutka kada je evidentirana uplata i potvrđena porudžbina

Dostava proizvoda u roku od 72 sata

Za odrđene kategorije proizvoda ulogovani kupci dobijaju dodatni popust.

Dostava za celu Srbiju

Plaćanje na 12 mesečnih rata putem Banca Intesa kreditnih kartica.

Plaćanje putem Web kredita banaka sa kojima prodavac ima saradnju

Plaćanje preko računa / virmanski

Specifikacija i karakteristike

Bar-kod: 4710483947421

Težina i dimenzije

Širina: 26,7 cm
Visina: 30,5 cm

Procesor

Tip: AMD
Socket (Baza): AMD AM5
Serija čipseta: AMD X870E
Integrisan procesor: -
Broj socket-a: 1

Vrsta i karakteristike

Format matične ploče: E-ATX
Gaming

RAM

Tip RAM memorije: DDR5
Broj RAM slotova: 4
Maksimalna RAM memorija: 256 GB
Brzina prenosa: 8.200 MT/s

Software

Kompatibilnost: Windows 10 64-bit
Kompatibilnost: Windows 11 64-bit
BIOS: 256Mb AMI UEFI Legal BIOS with GUI support

Mreža i konekcija

Wi-Fi
LAN priključak (Ethernet): 1x Realtek RTL8126
LAN priključak (Ethernet): 1x 5 Gigabit LAN 10/100/1000/2500/5000 Mb/s
Bluetooth
Integrisana mrežna kartica
Bluetooth verzija: Bluetooth 5.4
Wi-Fi standardi: Wi-Fi 7 Module 802.11be 2x2
Wi-Fi standardi: Supports IEEE 802.11a/b/g/n/ac/ax/axe/be
Wi-Fi standardi: Supports 2.4GHz/5GHz/6GHz frequency band
Wi-Fi standardi: 160MHz channel bandwidth with 6GHz frequency band

Grafika

HDMI: 1x HDMI 2.1
HDMI: TMDS/FRL 8G, HDR, HDCP 2.3
Integrisana grafička kartica: -
Multi GPU podrška

USB

USB: 2x USB 2.0
USB: 8x USB 3.2
USB: 2x USB-C (USB4)

Zvuk

S/PDIF: 1x S/PDIF Out
3.5mm: 1x Mic In
3.5mm: 1x Line out
Integrisana zvučna kartica
Kodeci zvučne kartice: Realtek ALC4082 Audio Codec
Kodeci zvučne kartice: ESS SABRE9219 DAC for Rear Panel Audio (130dB SNR)
Kodeci zvučne kartice: Nahimic Audio

Skladištenje

Broj M.2 slotova: 4
Broj SATA slotova: 6
RAID kontroler
Tip RAID-a: RAID 0
Tip RAID-a: RAID 1
Tip RAID-a: RAID 10

Slotovi za proširenje

Broj PCIe slotova: 2
PCIe slot: 2x PCI Express 5.0

Ostalo

Hlađenje: Pasivno
Ostalo: Taichi serija - vrhunska matična ploča sa flagship specifikacijama. Ova ploča donosi najviši nivo hardverskih karakteristika, izuzetno snažan sistem napajanja, USB4 Type-C portove i funkcije prilagođene DIY korisnicima. Namenjena je zahtevnim, high-end gejmerima, kombinujući luksuzan dizajn i vrhunske performanse. Izuzetna produktivnost: PCIe Gen5 (grafika, M.2), Dual Channel DDR5, USB4 Type-C portovi (40 Gb/s) Beskompromisna izdržljivost: Serverski Low-Loss PCB 24+2+1 faza napajanja, 110A SPS za VCore+SOC, uz uvećani hladnjak Fleksibilan integrisani I/O štit 20K dugotrajni „Black Caps“ kondenzatori (visokokvalitetni, provodljivi polimerni kondenzatori) Ultrabrza povezivost: 5G LAN, 802.11be Wi-Fi 7 modul ASRock Lightning Gaming portovi Jednostavno ažuriranje: BIOS Flashback taster, ASRock Auto Driver Installer Moguća su odstupanja karakteristika proizvoda u zavisnosti od revizije matične ploče CPU: Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors Memory: Dual Channel DDR5 Memory Technology 4 x DDR5 DIMM Slots Supports DDR5 ECC/non-ECC, un-buffered memory up to 8200+(OC) Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules Graphics: Integrated AMD RDNA™ graphics (Actual support may vary by CPU) 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz Audio: 5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec) WIMA Audio Capacitors (For Rear Outputs) ESS SABRE9219 DAC for Rear Panel Audio (130dB SNR) Individual PCB Layers for R/L Audio Channel Direct Drive Technology on Front headphone port (Supports up to 600 Ohm headsets) Expansion Slots: CPU: 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes Chipset: 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module Supports AMD CrossFire™ Storage: Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices Software: ASRock Motherboard Utility (A-Tuning) ASRock Polychrome SYNC UEFI: ASRock EZ Mode ASRock Full HD UEFI ASRock Auto Driver Installer ASRock Instant Flash

Konektori

Spisak konektora na zadnjoj strani: 2 x Antenna Ports 1 x HDMI Port 1 x Optical SPDIF Out Port 2 x USB4 Type-C Ports (40 Gb/s)* 5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_12 are Lightning Gaming Ports.) 3 x USB 3.2 Gen1 Type-A Ports (USB32_34 supports Ultra USB Power.) 2 x USB 2.0 Ports 1 x RJ-45 LAN Port 1 x Clear CMOS Button 1 x BIOS Flashback Button 1 x Line Out Jack (Gold Audio Jack) 1 x Microphone Input Jack (Gold Audio Jack) * Supports USB PD 3.0 up to 5V@3A (15W) charging
Spisak internih konektora: 3 x Thermistor Cable Headers 1 x Power LED and Speaker Header 1 x RGB LED Header 3 x Addressable LED Headers 2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control) 1 x Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) 1 x Front Panel Audio Connector (15μ Gold Audio Connector) 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) 1 x Dr. Debug with LED 1 x Power Button with LED 1 x Reset Button with LED
